JW-F30
JW
The JW-F30 compact fiber laser marking machine is designed for industrial applications requiring precise and permanent marking on various materials. This model offers optional laser powers of 20W, 30W, 50W, 60W and 100W, with laser sources available from Raycus, Max and JPT. The machine supports multiple marking areas ranging from 75×75mm to 250×250mm, making it suitable for both small components and larger workpieces.
This portable fiber laser marking machine features a compact design with a net weight of 35kg, allowing for easy relocation between different workstations. It operates on a wide voltage range of 110V-240V, 50-60Hz, compatible with power systems in most regions. The machine is suitable for marking metals, some plastics, some stones, rubber and leather materials.
Parameter | Specification |
Product name | JW-Portable fiber laser marking machine |
Laser type | Fiber laser |
Laser power (optional) | 20W / 30W / 50W / 60W / 100W |
Laser source (optional) | Raycus / Max / JPT |
Marking area (optional) | 75×75mm / 100×100mm / 150×150mm / 175×175mm / 200×200mm |
Galvo | Sino |
Power supply | Taiwan Meanwell |
Control system | Beijing JCZ |
Control software | Ezcad |
Laser wavelength | 1064nm |
Marking speed | ≤8000mm/s |
Minimum line width | ±0.01mm |
Marking depth | 0-3mm (depends on materials) |
Character height | ±0.2mm |
Working accuracy | ±0.002mm |
Power demand | 110V-240V, 50-60Hz |
Net weight | 35kg |
After packaging size | 81×51×58cm, 50kg |
The machine incorporates several key components that contribute to its performance. It uses Sino-galvo vibration mirrors for precise and fast marking operations. The field mirror is selected to reduce laser beam consumption, while the Taiwan Meanwell power supply provides stable electrical output. The system features double red light positioning for accurate workpiece alignment and an electric lifting shaft with speed adjustment for convenient operation.
This fiber laser marking machine for metal is widely used across multiple industries for various marking tasks. It can create permanent marks on stainless steel, aluminum, brass, copper and other metal materials. The machine is also capable of marking some non-metal materials including certain plastics, rubber and leather.
Common applications include logo marking, serial number engraving, QR code printing, and bar code marking on industrial components. The machine is suitable for use in integrated circuit chips, computer accessories, industrial bearings, watches, electronic and communication products, aerospace components, automotive parts, household appliances, hardware tools, dies, wire and cable, food packaging, jewelry and tobacco industries.
Optional accessories are available to expand the machine's capabilities. These include rotary axes D69 for rings, D80 for cups, pen rotary for cylindrical objects, EZCAD3 software for 3D engraving, 2D tables, and cutting fixtures for jewelry applications.
We offer both wholesale and retail sales models for this industrial fiber laser marking machine, with a minimum order quantity of 1 unit. Custom configurations are available to meet specific commercial procurement requirements.
The delivery lead time is 2-7 working days after receiving payment. For bulk orders, we can arrange shipping by sea, air or railway through reliable forwarders. Standard export packaging is used, with major products packed in export plywood cases and small products in thick cartons to ensure product integrity during transportation.
Accepted payment methods include T/T, PayPal and Alipay, with transactions available in USD or RMB currencies. We provide OEM services for overseas distributors and agents looking to expand their product offerings.
Liaocheng Jingwei Laser Equipment Co., Ltd. was founded in 2013 and is based in Liaocheng, Shandong, China. The company operates as a professional factory integrating research and development, manufacturing, sales and service. We specialize in laser engraving and cutting machines, desktop laser stamp engraving machines, fiber laser marking machines, related parts and WD series machines.
Our company has obtained CE certification and was recognized as a High-Tech Enterprise in November 2023 with certificate number GR202337001624, valid for three years. We have focused on the laser industry for 20 years, serving customers worldwide with our laser equipment solutions.
A 30W fiber laser marking machine can engrave most metals including stainless steel, aluminum, brass and copper. It can also mark some plastics, certain stones, rubber and leather materials. The marking depth ranges from 0-3mm depending on the specific material.
Raycus, Max and JPT are three different manufacturers of fiber laser sources. Each offers different performance characteristics and price points. All three options are compatible with the JW-F30 machine and provide stable laser output for industrial marking applications.
The JW-F30 fiber laser marking machine has a maximum marking speed of 8000mm/s. Actual marking speed will vary depending on factors such as the complexity of the design, marking depth required and the material being marked.
This fiber laser engraving machine offers a working accuracy of ±0.002mm, with a minimum line width of ±0.01mm. This level of precision makes it suitable for marking small components and intricate designs in industrial manufacturing environments.
Yes, we provide after-sales support for all our laser equipment. This includes technical assistance, replacement parts and troubleshooting guidance to help ensure your machine operates smoothly for commercial production needs.
To discuss your specific requirements or request a quotation for the JW-F30 30W compact fiber laser marking machine, please contact our sales team. We can provide detailed information about custom configurations and bulk pricing options for your business operations.
